What's your Product Specification
| DS-2CD6810F/C |
| Dual-Lens People Counting Camera |
| Support real-time people entering/exiting/passing by data. |
| Support statistical traffic report based on configurable time interval (day/week/month/year). |
| Flash memory storing people counting data |
| 1/3'' progressive scan CMOS sensor |
| Support Smart Codec, high bandwidth efficiency, low time delay and optimized bit rate. |
| Support 3D DNR. |
| Black and white image |
| Support teo video streams |
| Camera | |
| Image Sensor: | 1/3" Progressive Scan CMOS |
| Signal System: | PAL/NTSC |
| Shutter time: | 1/25 s - 1/10,000 s |
| Lens: | 2.0/2.8mm optional |
| Lens Mount: | M12 |
| Adjustment Range: | 2.0 mm, horizontal field of view: 100° |
| 2.8 mm, horizontal field of view: 82° | |
| Digital noise reduction: | 3D DNR |
Compression Standard | |
| Video Compression: | H.264 |
| H.264 code profile: | Baseline Profile/Main Profile |
| Video bit rate: | 32Kbps~8Mbps |
| Dual Stream: | Yes |
Image | |
| Max. Image Resolution: | 640 × 960 |
| Frame Rate: | Main stream: |
| 50Hz: 25fps (640 × 480) | |
| 60Hz: 24fps (640 × 480) | |
| Sub Stream: | 50Hz: 25fps (640 × 960) |
| 60Hz: 24fps (640 × 960) | |
| Image Settings: | Brightness is adjustable by client software or web browser |
| 3D DNR: | Support |
| ROI: | Support 1 fixed region for each stream |
Network | |
| Alarm Trigger: | Motion detection, tampering alarm, HDD full, HDD error, network disconnected, IP address conflicted, illegal login |
| Protocols: | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| General Function: | One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy |
| mask, Watermark, IP address filtering | |
| System Compatibility: | ONVIF (Profile S, Profile G),ISAPI |
Intelligent | |
| People Counting: | Support separate counting of people entering, exiting, and passing by |
Interface | |
| Communication Interface: | 1 RJ45 10M/100M self-adaptive Ethernet port, 1 RS-485 interface |
| Alarm: | 1 input, 1 output (up to DC 24 V, 1A or AC 110 V, 500mA ) |
| Reset Button: | Yes |
General | |
| Operation Condition: | -10 °C to + 40 °C (+14 °F to +104 °F), Humidity 10% to 90%, no condensing |
| Power Supply: | 12 VDC ± 25%, PoE (802.3af Class3) |
| Power Consumption: | Max. 7 W |
| Dimensions: | 194 × 70.2 × 35.8 mm (7.64″ × 2.76″ × 1.4″) |
| Weight: | 271 g (0.6 lb) |
