Automatic Passenger Counter Flap Barrier Security Solutions Access Control Flap Gate

Automatic 304 stainless steelaccess control  NFC/RFID/face recognition smart swing barrier gate Dimension1200*300*1000mmCase MaterialSS304 stainless steel,acrylicPass width550mmMaterial thickness1.0mm-1.2mmMechanismDC 24V Brushless motorMotherboardOne-driving-twoPassage directionSingle directional / Bi-directionalPassi

Featured Products

Automatic 304 stainless steelaccess control  NFC/RFID/face recognition smart swing barrier gate Automatic Passenger Counter Flap Barrier Security Solutions Access Control Flap Gate
Dimension1200*300*1000mm
Case MaterialSS304 stainless steel,acrylic
Pass width550mm
Material thickness1.0mm-1.2mm
MechanismDC 24V Brushless motor
MotherboardOne-driving-two
Passage directionSingle directional / Bi-directional
Passing rate/NO35-40persons/min
Passing rate/NC20-30persons/min
Opening methodID / IC card reader, infrared sensor, exit button, etc.
Communication interfaceDry contact
Protection functionCurrent anti-pinch, infrared anti-pinch, illegal intrusion infrared alarm
MCBF>=6million times
Infrared sensor3 pairs(can be customized as 4 pairs)
Power30-60w
Working temperature-20ºC~75ºC
Flap barrier gate is one of the passage management equipment, mainly used for pedestrian passage management; it has the characteristics of fast opening, safety, and convenience, and is an ideal management and grooming device for high-frequency pedestrian access; it has been widely used in airports, subway stations, and stations , Docks, scenic spots, parks, student dormitories, unit pedestrian passages, etc., can cooperate with smart cards to realize off-type ticketing management system functions and form unattended management of personnel entry and exit. Basically composed of a main box and a movable wing board, it has a blocking function for unauthorized personnel
1,With the function of self-reporting failure prompt, it is convenient for users to use and maintain;
2,It has the functions of passing instructions and channel instructions;
3,Has a normally open button function
4,It has the functions of automatic opening of the swing door after power failure and automatic closing after power on;
5,With line self-check function;
6,It has an alarm function for illegal intrusion;
7,With triple anti-pinch protection function;
8,The access mode can be adjusted arbitrarily;
9,The closing time and method can be adjusted arbitrarily;


Automatic Passenger Counter Flap Barrier Security Solutions Access Control Flap Gate
Automatic Passenger Counter Flap Barrier Security Solutions Access Control Flap Gate
Automatic Passenger Counter Flap Barrier Security Solutions Access Control Flap Gate



Shenzhen Zenidea Intelligent Technology Co., Ltd, a high-tech enterprise with 13 years experience specializing in the production of turnstiles and smart parking system. It is an enterprise integrating production, research and development, and sales. Obtained 30+ patent certificates. In the product production process, the product needs to go through 320 production processes, 12 quality inspection processes, and 72-hour aging process. In terms of software, we continue to optimize and upgrade standardized products and special customization requirements based on market application requirements and customer experience. We always insist on continuously innovating technology, and strive to create a global security industry boutique, to provide customers with better products.
Our production range includes tripod turnstiles, swing barrier gates, speed gates ,full height turnstiles, parking boom barrier and revolving doors which are widely used in subways, office building and other public area
> 7000m³ manufacturing center located in Shenzhen,China
> 9 R&D centers across China to provide timely and effective technical support
> 13 years of R & D and production experience
> 30+ Patents and various other related certificates (CE,RoHS,ISO9001,CNAS,IAF)
> Top 10 Security  Brands in China
> Appraised as a high-tech enterprise six consecutive years
> 20+ footprint,products sold to 20+ countries
Automatic Passenger Counter Flap Barrier Security Solutions Access Control Flap Gate
Automatic Passenger Counter Flap Barrier Security Solutions Access Control Flap Gate
Automatic Passenger Counter Flap Barrier Security Solutions Access Control Flap Gate
Automatic Passenger Counter Flap Barrier Security Solutions Access Control Flap Gate
Automatic Passenger Counter Flap Barrier Security Solutions Access Control Flap Gate
FAQ
1.How about your company's actual strength?
7000m3 manufacturing center located in Shenzhen,China
9 R&D centers across China to provide timely and effective technical support
13 years of R & D and production experience
30+ Patents and various other related certificates (CE,RoHS,ISO9001,CNAS,IAF)
Top 10 Security Brands in China
2.How do you do after-sale service?
Free lifetime technical support(video / picture / remote assistance)
24/7 technical online service
Free replacement of hardware damaged during the warranty period (except for human factors).
3.How about your package?
Seaworthy wooden case + Foam.
Wooden case package of Export exempted from inspection plus pearl wool and plastic wrap.
4.How about the lead time?
Stock products: 5-7 days
Out-of-stock products: According to the production schedule,12-20 days.
5.How about the payment method?
T/T , Western Union, PayPal...
